StormTech® SC-310
The StormTech SC-310 is an ideal solution for Stormwater systems requiring low rise and wide span solutions. This low-profile chamber allows the storage of large volumes at minimum depths.
Overview
The StormTech SC-310 cumulative storage per chamber assumes 40% stone porosity. Calculations are based upon a 150mm (6") stone base under chambers.
Chamber Sizing
- Size (L x W x H) 2,100 mm x 850 mm x 400 mm (85.4” x 34.0” x 16.0”)
- Chamber Storage 0.42 m³ (14.7 ft³)
- Min. Installed Storage* 0.83 m³ (29.3 ft³)
- Weight 16.8 kg (37.0 lbs)
- Shipping 41 chambers/pallet 108 end caps/pallet 18 pallets/truck
*Assumes 150mm (6") stone above and below chambers and 40% stone porosity.
